Name: SmartConnect UPS SMT 1500VA Rack 2HE
Brand: 60000582
SKU: 168256

text.skipToContent text.skipToNavigation

ID: 168256 APC ID: SMT1500RMI2UC

SmartConnect UPS SMT 1500VA Rack 2HE

Detailed product title

APC SmartConnect UPS SMT 1500VA Rack 2HE

Product colour Black

ship in 4-7 days

Added to cart

ship in 4-7 days

Product description

Supports cold start
Allows temporary battery operation if mains power fails.
Energy consumption meter
Indication of usage in kilowatt hours for energy-conscious users.
Green operating mode
Patent-pending operating mode in which unused electrical components are switched off when power conditions are good, allowing very high operating efficiency to be achieved without compromising safety.
High online efficiency
Reduces electricity costs, generates less waste heat.
Intuitive LCD user interface
Easy-to-read interface with accurate information in multiple languages and support for on-site UPS configuration with user-friendly navigation buttons.
Display of the date for battery replacement
The dynamic display of the recommended battery replacement date in month and year makes long-term maintenance planning easier.
Purely sinusoidal output signal in battery operation
Simulates mains power for the highest possible compatibility with servers and sensitive electronic systems with active power factor correction.
Individual module with switchable outputs
Individual output group for separate control via the UPS system for the targeted restart of systems that are no longer responsive, the successive switching on or off of systems or the switching off of non-critical loads.
SmartSlot
Equip your UPS with individual functions using management cards.
Charging the battery with temperature compensation
Extends the life of the battery by regulating the charging voltage according to the actual battery temperature.

Technical specifications

Logistics data

Products per pallet

Packaging content

Cables included

RS-232,USB cable

Other features

Certification

CE, EAC, EN / IEC 62040-1, EN / IEC 62040-2, Energy Star 1.0 (EU), RCM, TÜV, VDE

Lieferumfang

Resource CD	Yes
Rack mount kit	Yes

Ports & interfaces

USB port

Sustainability

Sustainability certificates

ENERGY STAR,Green Premium

Weight & dimensions

Package weight	31,910
Package depth	603
Package width	594
Package height	251

Power

Number of batteries supported

Battery

Hot-swap battery	Yes
Waveform	Sine
Cold start	Yes
Automatic battery test	Yes
Battery life (max)	6

Packaging content

Manual

Battery

Battery recharge time

Features

Audible alarm(s)	Yes
UPS topology	Line-Interactive
Audible alarm modes	Alarm when on battery,Low battery alarm
Auto-restart	Yes
Surge energy rating	459
Output power capacity	1.5
Input operation voltage (max)	302
Input operation voltage (min)	151
Output operation voltage (min)	220
Output operation voltage (max)	240

Weight & dimensions

Weight	26,100
Height	86
Width	432
Depth	477

Operational conditions

Operating relative humidity (H-H)	0 - 95
Storage temperature (T-T)	-15 - 45
Operating temperature (T-T)	0 - 40
Operating altitude	0 - 3000
Storage relative humidity (H-H)	0 - 95
Non-operating altitude	0 - 15000

Features

Noise level

Display

Response time

Battery

Battery technology

Sealed Lead Acid (VRLA)

Ports & interfaces

Serial interface type

RJ-45

Features

Output voltage	230
Input frequency	50/60
Output power	1,000
Output frequency	50/60

Ports & interfaces

Power plug	C14 coupler
AC outlet types	C13 coupler,IEC Jumpers
Serial interface	Yes
SmartSlot	Yes
AC outlets quantity	4

Features

LED indicators

Design

Rack capacity

Design

Product colour	Black
Form factor	Rackmount
