- ColorEdge CS2400S Computerbildschirm 61,2cm (24,1") 1920x1200 Pixel WUXGA LED 1350:1 410 cd/m² Schwarz
+3 Images
8 Images
Product description
The ColorEdge CS2400S is the perfect entry into the world of maximum precision: the panel offers extremely wide coverage of the relevant colour spaces (e.g. 99 % AdobeRGB). The Digital Uniformity Equalizer (DUE) ensures homogeneous image representation and the 16-bit look-up table guarantees absolutely precise colour representation with up to 10 bits. On the one hand, the exact factory calibration guarantees the highest precision "out of the box". On the other hand, the regularly recommended recalibration is done in no time at all. This means that photographers, filmmakers or image editors can always rely on their monitor to show them an absolutely precise view of their image file. The docking functions via USB-C allow the image signal to be transferred and the monitor’s USB hub to be powered with just one cable. In addition, a mobile device can be supplied with up to 70 watts of charging current. In this way, the CS2400S becomes the central dock of the creative workflow with a flick of the wrist. Alternatively, the monitor can of course also be operated via HDMI or DisplayPort as well as USB-B upstream.
Technical specifications
Design
| Product colour | Black |
| Anti-glare screen | Y |
| VESA mounting | Y |
| Feet colour | Black |
| Panel mounting interface | 100 x 100 |
Bildschirm
| Display technology | LED |
| Native aspect ratio | 16:10 |
| Panel type | IPS |
| Screen shape | Flat screen |
| Display number of colours | 1.07 billion colours |
| RGB colour space | Adobe RGB |
| Contrast ratio (typical) | 1350:1 |
| Touchscreen | N |
| On Screen Display (OSD) | Y |
| Pixel pitch | 0.27 x 0.27 |
| Horizontal scan range | 15 - 76 |
| Viewable size, horizontal | 518.4 mm |
| Vertical scan range | 23 - 61 |
| Viewable size, vertical | 324 mm |
| Display diagonal | 24.1 " |
| Display resolution | 1920 x 1200 |
| Viewing angle, horizontal | 178 deg |
| Viewing angle, vertical | 178 deg |
| Pixel density | 94 ppi |
| Maximum refresh rate | 60 Hz |
| Adobe RGB coverage | 99 % |
| sRGB coverage (typical) | 100 % |
| Display brightness (typical) | 410 cd/m² |
Anschlüsse und Schnittstellen
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| HDCP | Y |
| USB Type-C DisplayPort Alternate Mode | Y |
| USB Power Delivery | Y |
| HDMI | Y |
| USB upstream port type | USB Type-B,USB Type-C |
| USB Type-A downstream ports quantity | 4 |
| Number of USB Type-C upstream ports quantity | 1 |
| Number of USB Type-B upstream ports quantity | 1 |
| Built-in USB hub | Y |
| USB Power Delivery up to | 70 W |
Video
| HD type | WUXGA |
Maus
| Response time | 19 ms |
Leistungen
| Flicker-free technology | Y |
Grafik
| NVIDIA G-SYNC | N |
| AMD FreeSync | N |
Ergonomie
| Height adjustment | 155 mm |
Nachhaltigkeit
| Sustainability certificates | CB,CCC,CE,ChinaCompulsory Certification(CCC),Fed |
| Sustainability compliance | Y |
Technische Details
| Market positioning | Graphics design |
| AC input voltage | 100 - 240 |
Verpackungsdaten
| Cables included | AC,HDMI,USB Type-C to USBType-C |
| Quick start guide | Y |
Leistung
| Energy efficiency class (SDR) | E |
| Energy efficiency class (HDR) | Not available |
| Power consumption (standby) | 0.3 W |
| AC input frequency | 50/60 |
| Power consumption (max) | 149 W |
| Energy consumption (SDR) per 1000 hours | 16 kW.h |
Betriebsbedingungen
| Operating relative humidity (H-H) | 20 - 80 |
| Operating temperature (T-T) | 0 - 35 |
Sonstige Funktionen
| Built-in camera | N |
| Built-in speaker(s) | No |
| Height adjustment | Y |
| Pivot | Y |
| Swivelling | Y |
| Power consumption (typical) | 18 W |
| Swivel angle range | 0 - 344 |
| Tilt angle range | -5 - 35 |
| Display diagonal (metric) | 61.1 cm |
| Pivot angle | 0 - 90 |
Gewicht und Abmessungen
| Height (with stand) | 396 mm |
| Depth (with stand) | 245 mm |
| Width (with stand) | 554.4 mm |
| Weight (with stand) | 8,200 g |
| Weight (without stand) | 5,200 g |
| Width (without stand) | 554.4 mm |
| Height (without stand) | 362 mm |
| Depth (without stand) | 64 mm |
