ID: 481943 EIZO ID: EV2740X-WT

FlexScan EV2740X-WT Computerbildschirm 68,6cm (27") 3840x2160 Pixel 4K Ultra HD 2000:1 350 cd/m² LCD Weiß

Detailed product title

EIZO FlexScan EV2740X-WT. Display diagonal: 68.6 cm (27"), Display resolution: 3840 x 2160 pixels, HD type: 4K Ultra HD, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). Built-in USB hub. VESA mounting, Height adjustment. Product colour: White

Response time 5ms

Display resolution 3840 x 2160pixels

Contrast ratio (typical) 2000:1

Display brightness (typical) 350cd/m²

Display diagonal 27"

Product colour White

Height adjustment Y

Built-in speaker(s) Y

Product colour *

please ask for availability

Added to cart

please ask for availability

Product description

The EV2740X makes a clear statement for performance. 4K UHD resolution, USB-C docking and 94 W Power Delivery are convincing. Its 163 dpi display quality ensures crisp graphics and text. Docking convenience via its USB-C interface makes the FlexScan EV2740X the ideal display solution for professional office or CAD applications. Switching smoothly between office and home office is a breeze thanks to the USB-C port. Especially notebook and tablet users benefit from this. A single connection to the computer is sufficient for charging power, video signal, audio and USB data including network. The casing is available in black or white; even the cables are color-coordinated. The monitor is equipped with two HDMI ports as well as one DisplayPort and USB-C port each. With its two USB upstream ports, the EV2740X can be used as a keyboard/mouse switcher. For example, if both a home PC and a company computer are connected to the monitor in the home office, both computers can be operated with a single keyboard and mouse. When using its Picture-by-Picture function, it even displays two signal sources simultaneously.

Technical specifications

Leistungen

Flicker-free technology	Y
Low Blue Light technology	Y

Design

Product colour

White

Power

Energy efficiency class (SDR)	D
Energy efficiency class (HDR)	Not available
Power consumption (typical)	16 W
Power consumption (standby)	0.35 W
AC input voltage	100 - 240
AC input frequency	50/60
Power consumption (max)	186 W
Energy consumption (SDR) per 1000 hours	18 kW.h

Lieferumfang

Cables included

AC,USB Type-C to USB Type-C

Technische Details

Market positioning

Office

Verpackungsdaten

Quick start guide

Sonstige Funktionen

Digital horizontal frequency	31 - 135
Digital vertical frequency	29 - 61
Display diagonal (metric)	68.5 cm

Sustainability

Sustainability certificates	ENERGY STAR,EPEAT Climate +,EPEAT Gold,TCO
Sustainability compliance	Y
Compliance certificates	CB,CCC,CE,China RoHS,Federal Communications Commission (FCC),GS mark,ICES,PSE,RCM,RoHS,cTUVus,UKCA,VCCI,WEEE

Ergonomics

Cable lock slot type	Kensington
Cable lock slot	Y
VESA mounting	Y
On Screen Display (OSD) languages	DEU,ENG,ESP,FRE,ITA,SWE
Height adjustment	Y
Pivot	Y
On Screen Display (OSD)	Y
Swivelling	Y
Swivel angle range	-90 - 90
Tilt angle range	-5 - 35
Panel mounting interface	100 x 100 mm
Height adjustment	195 mm
Pivot angle	0 - 90

Multimedia

Built-in camera	N
Built-in speaker(s)	Y

Display

Backlight type	LED
Display technology	LCD
Panel type	IPS
Screen shape	Flat screen
Display number of colours	16.7 million colours
RGB colour space	sRGB
Anti-glare screen	Y
Touchscreen	N
Pixel pitch	0.155 x 0.155
Viewable size, horizontal	597 mm
Viewable size, vertical	336 mm
Response time	5 ms
Display diagonal	27 "
Display resolution	3840 x 2160 pixels
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Pixel density	163 ppi
Maximum refresh rate	60 Hz
sRGB coverage (typical)	100 %
Display brightness (typical)	350 cd/m²

Graphics

NVIDIA G-SYNC	N
AMD FreeSync	N

Mouse

Certification

CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 10, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC

Network

Ethernet LAN

Video

Supported graphics resolutions	720 x 400,1280 x 1024 (SXGA),3840 x 2160,800 x 600 (SVGA),2560 x 1440,1600 x 1200 (UXGA),1024 x 768 (XGA),1680 x 1050 (WSXGA+),640 x 480 (VGA),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA)
HD type	4K Ultra HD

Projector

Native aspect ratio	16:9
Contrast ratio (typical)	2000:1

Ports & interfaces

HDMI ports quantity	2
Headphone connectivity	3.5 mm
DisplayPorts quantity	1
Headphone outputs	2
HDCP	Y
USB Type-C DisplayPort Alternate Mode	Y
USB Power Delivery (USB PD)	Y
HDMI	Y
Headphone out	Y
USB upstream port type	USB Type-B,USB Type-C
Number of upstream ports	2
USB Type-A downstream ports quantity	3
USB Type-C downstream ports quantity	1
Number of USB Type-C upstream ports quantity	1
Number of USB Type-B upstream ports quantity	1
Built-in KVM switch	Y
Built-in USB hub	Y
USB Power Delivery up to	94 W

Weight & dimensions

Height (with stand)	565 mm
Depth (with stand)	242 mm
Width (with stand)	612 mm
Weight (with stand)	8,200 g
Weight (without stand)	5,500 g
Width (without stand)	612 mm
Height (without stand)	359 mm
Depth (without stand)	61 mm
