- 4 Port KVM Switch DisplayPort/USB 3.0 Hub 4K 30Hz
+3 Images
8 Images
Product description
Control four DP computers using a single console with a built-in USB 3.0 hub for sharing additional peripheral devices
This 4-Port USB 3.0 DisplayPort KVM switch lets you control four DisplayPort (DP) computers with a single monitor, keyboard and mouse. The KVM also features 3.5 mm audio and a built-in 3-port USB 3.0 hub.
Convenient and cost-effective USB 3.0 peripheral sharing
This KVM switch offers a built-in 3-port USB 3.0 hub that's separate from your HID keyboard and mouse, so you can share USB peripheral devices between each connected computer and avoid the expense of separate equipment. The USB 3.0 hub automatically switches your connected USB devices to the selected computer, saving you the hassle of disconnecting and reconnecting your peripherals.
With support for USB 3.0, you can achieve data transfer rates up to 5Gbps, to ensure flawless performance for your USB peripherals - great for quickly transferring data to external USB 3.0 drives.
Astonishing picture quality
Offering support for resolutions up to Ultra HD 4K at 30 Hz, this 4-port DisplayPort KVM switch has the ability to drive large DP displays with ease, making it ideal for graphical applications that require high-resolution video support.
Complete multimedia control
The KVM switch features auxiliary 3.5 mm audio ports that enable you to share independent analog audio, from each of your connected computers, with your desktop speaker set. Independent audio, along with 4K DP video, gives you full multimedia control between different computers, making this KVM perfect for creative professional applications such as video and sound design or editing.
The SV431DPU3A2 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Rackmount your KVM switch
If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.
The StarTech.com Advantage
- Easily share peripheral devices using the built-in USB 3.0 hub
- Astonishing picture quality with support for Ultra HD 4K resolutions
- Full multimedia control with separate 3.5 mm auxiliary support
This 4-Port USB 3.0 DisplayPort KVM switch lets you control four DisplayPort (DP) computers with a single monitor, keyboard and mouse. The KVM also features 3.5 mm audio and a built-in 3-port USB 3.0 hub.
Convenient and cost-effective USB 3.0 peripheral sharing
This KVM switch offers a built-in 3-port USB 3.0 hub that's separate from your HID keyboard and mouse, so you can share USB peripheral devices between each connected computer and avoid the expense of separate equipment. The USB 3.0 hub automatically switches your connected USB devices to the selected computer, saving you the hassle of disconnecting and reconnecting your peripherals.
With support for USB 3.0, you can achieve data transfer rates up to 5Gbps, to ensure flawless performance for your USB peripherals - great for quickly transferring data to external USB 3.0 drives.
Astonishing picture quality
Offering support for resolutions up to Ultra HD 4K at 30 Hz, this 4-port DisplayPort KVM switch has the ability to drive large DP displays with ease, making it ideal for graphical applications that require high-resolution video support.
Complete multimedia control
The KVM switch features auxiliary 3.5 mm audio ports that enable you to share independent analog audio, from each of your connected computers, with your desktop speaker set. Independent audio, along with 4K DP video, gives you full multimedia control between different computers, making this KVM perfect for creative professional applications such as video and sound design or editing.
The SV431DPU3A2 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Rackmount your KVM switch
If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.
The StarTech.com Advantage
- Easily share peripheral devices using the built-in USB 3.0 hub
- Astonishing picture quality with support for Ultra HD 4K resolutions
- Full multimedia control with separate 3.5 mm auxiliary support
Technical specifications
Design
Built-in display | N |
LED indicators | Link,Power |
Anschlüsse und Schnittstellen
HDCP | Y |
Ethernet LAN | N |
USB connector type | USB Type-A |
DC-in jack | Y |
USB version | 3.2 Gen 1 (3.1 Gen 1) |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 3 |
Video port type | DisplayPort |
Keyboard port type | USB |
Mouse port type | USB |
Console ports | 3.5mm headphone,DisplayPort,USB A |
Number of computers controlled | 4 |
Console USB ports quantity | 4 |
Tastatur
Hot keys | Y |
Video
HD type | 4K Ultra HD |
Maus
Certification | CE, FCC, UL, PSE |
Leistungen
Daisy chain | N |
Audio channels | 2 |
Ergonomie
Plug and Play | Y |
Nachhaltigkeit
Sustainability certificates | RoHS |
Stromversorgung
Energy consumption | 18 W |
Technische Details
AC input voltage | 100-240 |
Verpackungsdaten
Quick installation guide | Y |
Package weight | 1,610 g |
Package depth | 297 mm |
Package width | 244 mm |
Package height | 85 mm |
Rubber feet | Y |
Leistung
Output current | 1.5 A |
Compatible power plug types | AU,EU,UK,US |
Betriebsbedingungen
Operating relative humidity (H-H) | 0 - 80 |
Storage temperature (T-T) | -10 - 60 |
Operating temperature (T-T) | 0 - 40 |
Sonstige Funktionen
Power plug type | Type M |
Headphone outputs | 4 |
Rack mounting | Y |
Audio connections | Y |
Maximum resolution | 3840 x 2160 |
Output voltage | 12 |
Maximum operating distance | 10 m |
Audio support | Y |
IP control | N |
Gewicht und Abmessungen
Weight | 1,062 g |
Height | 43 mm |
Width | 130 mm |
Depth | 220 mm |
Logistische Daten
Harmonized System (HS) code | 85176200 |
