- StarTech Dual DisplayPort USB KVM-Switch with Audio 2 Port














+2 Images
7 Images














Product description
Control two computers from a single console, with high-resolution DisplayPort video, USB keyboard, mouse, and audio
The SV231DPUA 2-Port USB DisplayPort KVM Switch delivers dual computer KVM control, for demanding high definition multimedia applications. Supporting DisplayPort connections with a native resolution of 2560 x 1600, and support for both 7.1 HD digital audio (when connected to supporting displays and sources) and 3.5mm stereo analog audio/mic.
A simple, yet comprehensive KVM solution, the 2-port switch features both front-panel push-buttons and hotkey switching, and offers a small form factor design with connection ports situated on the rear panel. A Plug-and-Play USB 2.0 hub port allows you to share an additional USB peripheral between the 2 connected computers, avoiding the expense of purchasing duplicate peripheral devices.
A suitable solution for medical applications (MRI, X-ray diagnostics etc.), the KVM switch supports a maximum resolution of 3840 x 2400 at a reduced refresh rate.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Compatible with Mini-DisplayPort adapters, making it suitable for Apple MacBook connectivity
- Support for both analog and digital audio sources provides the versatility to use either connection depending on preference/availability
- USB peripheral sharing eliminates the expense of duplicate devices (printers, scanners, etc.)
The SV231DPUA 2-Port USB DisplayPort KVM Switch delivers dual computer KVM control, for demanding high definition multimedia applications. Supporting DisplayPort connections with a native resolution of 2560 x 1600, and support for both 7.1 HD digital audio (when connected to supporting displays and sources) and 3.5mm stereo analog audio/mic.
A simple, yet comprehensive KVM solution, the 2-port switch features both front-panel push-buttons and hotkey switching, and offers a small form factor design with connection ports situated on the rear panel. A Plug-and-Play USB 2.0 hub port allows you to share an additional USB peripheral between the 2 connected computers, avoiding the expense of purchasing duplicate peripheral devices.
A suitable solution for medical applications (MRI, X-ray diagnostics etc.), the KVM switch supports a maximum resolution of 3840 x 2400 at a reduced refresh rate.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Compatible with Mini-DisplayPort adapters, making it suitable for Apple MacBook connectivity
- Support for both analog and digital audio sources provides the versatility to use either connection depending on preference/availability
- USB peripheral sharing eliminates the expense of duplicate devices (printers, scanners, etc.)
Technical specifications
Design
Product colour | Black |
Built-in display | No |
Push button | Yes |
Logistics data
Harmonized System (HS) code | 85176200 |
Leistungen
Housing material | Steel |
Hot-Plug support | Yes |
Daisy chain | No |
Audio channels | 7.1 |
DDC2B support | Yes |
Stromversorgung
Power consumption (typical) | 24 W |
Power
AC input voltage | 110 - 240 |
Output current | 2 A |
Compatible power plug types | AU, EU, UK, US |
Verpackungsdaten
AC adapter included | Yes |
Package weight | 1300 g |
Package depth | 250 mm |
Package width | 100 mm |
Package height | 181 mm |
Rubber feet | Yes |
Sonstige Funktionen
Power plug type | Type M |
Manual | Yes |
Rack mounting | No |
External power adapter | Yes |
Audio connections | Yes |
Maximum resolution | 3840 x 2400 pixels |
Output voltage | 12 V |
Input current | 0.8 A |
Audio support | No |
IP control | No |
Sustainability
Sustainability certificates | RoHS |
Operational conditions
Operating relative humidity (H-H) | 0 - 80% |
Storage temperature (T-T) | -20 - 60 °C |
Operating temperature (T-T) | 0 - 40 °C |
Gewicht und Abmessungen
Weight | 1100 g |
Height | 44 mm |
Width | 220 mm |
Depth | 130 mm |
Ergonomics
Plug and Play | Yes |
LED indicators | Yes |
On Screen Display (OSD) | No |
Mouse
Certification | CE, UL, FCC, REACH |
Video
HD type | 4K Ultra HD |
Keyboard
Hot keys | Yes |
USB hub | Yes |
Ports & interfaces
DisplayPorts quantity | 2 |
Headphone outputs | 3 |
Ethernet LAN | No |
USB connector type | USB Type-A |
DC-in jack | Yes |
Number of microphone inputs | 3 |
Video port type | DisplayPort |
Keyboard port type | USB |
Mouse port type | USB |
Console ports | 3.5mm headphone, 3.5mm mic, DisplayPort, USB A |
Number of computers controlled | 2 |
Console USB ports quantity | 4 |
