- Dual-Port QSP+ Server Netzwerkkarte PCI Express 40 Gigabit QSFP
5 Images
Product description
Add two high-bandwidth 40 Gigabit fiber Ethernet ports to your server or workstation, using the QSFP+ transceiver of your choice
Get fast, high-bandwidth connectivity with this dual-port QSFP+ Network Interface Card. It adds two open QSFP+ slots to your server or workstation. The 40G NIC features an Intel controller and provides redundant network links with reliable performance. It’s ideal for high-demand database servers, virtualized servers and agile data centers that require infrastructure updates with no downtime.
Increase your network speed
This dual port QSFP+ server NIC card lets you take advantage of the speed and stability of a 40 Gigabit network, with data transfers of up to 40Gbps.
Add redundant connections in zero-downtime environments
With two QSFP+ ports, the PCIe NIC helps to prevent network downtime by adding fault-tolerant connections using two modules, to provide high-bandwidth network links to your mission-critical servers or workstations.
Add scalable network connections
With its open QSFP+ slots, the network interface card supports QSFP+ transceiver modules and is compatible with multimode and single-mode fiber, providing a scalable networking solution.
Enhance your network capabilities
The 40G NIC uses an Intel XL710 chipset providing reliable connectivity and convergent network features. It offers many advanced features including Intel Virtualization Technology for Connectivity.
The PEX40GQSFDPI is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- DUAL QSFP+ NETWORK CARD: Two port 40GbE converged network adapter for redundancy or can be aggregated for demanding applications; Data Center Bridging (DCB), virtualization & iSCSI offload support
- TECH SPECS: 2x 40 Gbps Open QSFP+ Ports
- MSA Compliant
Get fast, high-bandwidth connectivity with this dual-port QSFP+ Network Interface Card. It adds two open QSFP+ slots to your server or workstation. The 40G NIC features an Intel controller and provides redundant network links with reliable performance. It’s ideal for high-demand database servers, virtualized servers and agile data centers that require infrastructure updates with no downtime.
Increase your network speed
This dual port QSFP+ server NIC card lets you take advantage of the speed and stability of a 40 Gigabit network, with data transfers of up to 40Gbps.
Add redundant connections in zero-downtime environments
With two QSFP+ ports, the PCIe NIC helps to prevent network downtime by adding fault-tolerant connections using two modules, to provide high-bandwidth network links to your mission-critical servers or workstations.
Add scalable network connections
With its open QSFP+ slots, the network interface card supports QSFP+ transceiver modules and is compatible with multimode and single-mode fiber, providing a scalable networking solution.
Enhance your network capabilities
The 40G NIC uses an Intel XL710 chipset providing reliable connectivity and convergent network features. It offers many advanced features including Intel Virtualization Technology for Connectivity.
The PEX40GQSFDPI is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- DUAL QSFP+ NETWORK CARD: Two port 40GbE converged network adapter for redundancy or can be aggregated for demanding applications; Data Center Bridging (DCB), virtualization & iSCSI offload support
- TECH SPECS: 2x 40 Gbps Open QSFP+ Ports
- MSA Compliant
Technical specifications
Design
Farbe | Black |
LED indicators | Activity,Link |
Internal | Y |
Component for | PC/Server |
Anschlüsse und Schnittstellen
Ethernet LAN | N |
Host interface | PCI Express |
Connectivity technology | Wired |
Fiber optic connector | QSFP+ |
Fiber ports quantity | 2 |
PCI version | 3.0 |
Netzwerk
Full duplex | Y |
Jumbo frames support | Y |
Jumbo frames | 9,000 |
VLAN tagging | Y |
Software
Server operating systems supported | Windows Server 2008 R2,Windows Server 2012,Windows |
Merkmale
Maximum data transfer rate | 40,000 Mbit/s |
Nachhaltigkeit
Sustainability certificates | CE,RoHS |
Sustainability compliance | Y |
Systemanforderung
Linux operating systems supported | Y |
Windows operating systems supported | Windows 10,Windows 10Education,Windows 10Educati |
Lichtwellenleiter
Fiber ethernet cabling technology | 40GBASE-LR4,40GBASE-SR4 |
Kopfhörer
Chipset | Intel - XL710-BM2 |
Verpackungsdaten
Quick start guide | Y |
Package weight | 212 g |
Package depth | 207 mm |
Package width | 145 mm |
Package height | 40 mm |
Low-profile bracket | Y |
Betriebsbedingungen
Operating relative humidity (H-H) | 5 - 95 |
Storage temperature (T-T) | -20 - 85 |
Operating temperature (T-T) | 0 - 57 |
Sonstige Funktionen
Interface | Fiber |
Networking standards | IEEE 802.1Q,IEEE 802.3ad,IEEE 802.3ba,IEEE 802.3x |
Flow control support | Y |
Gewicht und Abmessungen
Weight | 127 g |
Height | 21 mm |
Width | 121 mm |
Depth | 181 mm |
Logistische Daten
Harmonized System (HS) code | 85176990 |
Master (outer) case height | 320 mm |
Master (outer) case width | 420 mm |
Master (outer) case length | 440 mm |
Products per master (outer) case | 40 ST |
