4 Images
Product description
- Provides 8 10/100/1000Mbps copper ports
- Auto-negotiation
- Auto MDI/MDI-X crossover function
- Supports IEEE 802.3x flow control for full duplex
- Supports back pressure flow control for half duplex
- Fully non-blocking Gigabit full wire speed switching performance
- Jumbo frame support
- Alarm relay output for power failure event and configured port link fault events
- Wide operating temperature range
- Supports Green Ethernet power saving
- Supports IEEE 802.3az Energy Efficient Ethernet
- Supports DIN-Rail mounting and panel mounting
- Industrial-rated emission and immunity performance
Technical specifications
Design
Stackable | N |
Anschlüsse und Schnittstellen
Ethernet LAN ports | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Netzwerk
Ethernet interface type | Gigabit Ethernet |
Full duplex | Y |
VLAN support | N |
Auto-negotiation | Y |
10G support | N |
Management-Funktionen
Switch type | Unmanaged |
Stromversorgung
Energy consumption | 10 W |
Sonstige Funktionen
Rack mounting | Y |
Dimensions (WxDxH) | 42 x 106 x 140 |
Gewicht und Abmessungen
Height | 42 mm |
Width | 106 mm |
Depth | 140 mm |
ID: 137485
Roline ID: 21.13.1161
Industrie Gigabit Switch 8xRJ-45
Detailed product title
Detailed product title
Roline Industrie Gigabit Switch 8xRJ-45
4 Images
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 8
Switch type Unmanaged
Gross:
incl.
vat.
immediately
Added to cart
Gross:
incl.
vat.
immediately
Product description
- Provides 8 10/100/1000Mbps copper ports
- Auto-negotiation
- Auto MDI/MDI-X crossover function
- Supports IEEE 802.3x flow control for full duplex
- Supports back pressure flow control for half duplex
- Fully non-blocking Gigabit full wire speed switching performance
- Jumbo frame support
- Alarm relay output for power failure event and configured port link fault events
- Wide operating temperature range
- Supports Green Ethernet power saving
- Supports IEEE 802.3az Energy Efficient Ethernet
- Supports DIN-Rail mounting and panel mounting
- Industrial-rated emission and immunity performance
Technical specifications
Design
Stackable | N |
Anschlüsse und Schnittstellen
Ethernet LAN ports | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Netzwerk
Ethernet interface type | Gigabit Ethernet |
Full duplex | Y |
VLAN support | N |
Auto-negotiation | Y |
10G support | N |
Management-Funktionen
Switch type | Unmanaged |
Stromversorgung
Energy consumption | 10 W |
Sonstige Funktionen
Rack mounting | Y |
Dimensions (WxDxH) | 42 x 106 x 140 |
Gewicht und Abmessungen
Height | 42 mm |
Width | 106 mm |
Depth | 140 mm |
