- SRVPM1KIL, Doppelwandler (Online), 1 kVA, 800 W, Sine, 160 V, 280 V
3 Images
Product description
High quality double conversion online UPS designed to meet the most important power requirements even in unstable power conditions. Automatic internal bypass The purely static bypass switch without a bypass contactor ensures fast and reliable switching to or from bypass. Designed for 125% of rated load. Automatic restart of connected loads after UPS shutdown Automatically starts up the connected equipment when mains voltage returns. ECO mode Operating mode in which unused electrical components are bypassed when power is OK to enable efficient operation without compromising availability Input current factor correction Reduces installation costs by allowing the use of smaller generators and thinner cables. Intelligent battery management An intelligent precision charging system optimizes the performance, lifespan and reliability of batteries. Intelligent Card Slot Equip your UPS with individual functions using management cards. LCD Display Manage the UPS locally using a character-based display that allows quick diagnosis based on stored alarm conditions and events Serial Interface Provides management of the UPS via a serial port. USB Interface Allows management of the UPS via the USB port.
Technical specifications
Design
Product colour | Black |
Form factor | Tower |
LED indicators | Y |
Anschlüsse und Schnittstellen
USB 2.0 ports | 1 |
Serial ports quantity | 1 |
Serial interface type | RS-232 |
Power plug | C14 coupler |
AC outlet types | C13 coupler |
Serial interface | Y |
SmartSlot | Y |
AC outlets quantity | 3 AC out |
Maus
Certification | CE, IEC 62040-1-1, IEC62040-1-2 REACH |
Leistungen
ECO mode | Y |
Merkmale
Audible alarm(s) | Y |
Crest factor | 3:1 |
UPS topology | Double-conversion (Online) |
Audible alarm modes | Alarm when on battery,Lowbattery alarm,Overload a |
Auto-restart | Y |
Surge energy rating | 600 J |
Output power capacity | 1 kVA |
Output voltage Total Harmonic Distortion (THD) | 3 % |
Input operation voltage (max) | 280 V |
Input operation voltage (min) | 160 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Batterie
Waveform | Sine |
Automatic battery test | Y |
Nachhaltigkeit
Sustainability certificates | RoHS |
Stromversorgung
Battery technology | Sealed Lead Acid (VRLA) |
Lieferumfang
Cables included | USB cable |
Leistung
Battery recharge time | 4 std |
Betriebsbedingungen
Operating relative humidity (H-H) | 0 - 95 |
Storage temperature (T-T) | -20 - 50 |
Operating temperature (T-T) | 0 - 40 |
Operating altitude | 0 - 3000 |
Storage relative humidity (H-H) | 0 - 95 |
Non-operating altitude | 0 - 14763.6 |
Sonstige Funktionen
Manual | Y |
USB port | Y |
Input frequency | 40/70 |
Output power | 800 W |
Nominal input voltage | 230 |
Nominal output voltage | 230 |
Gewicht und Abmessungen
Weight | 9,300 g |
Height | 223 mm |
Width | 145 mm |
Depth | 288 mm |
Battery weight | 10,600 g |
Battery width | 235 mm |
Battery height | 330 mm |
Battery depth | 365 mm |
Downloads
521390_document_EN_001
PDF Download
ID: 521390
APC ID: SRVPM1KIL
SRVPM1KIL, Doppelwandler (Online), 1 kVA, 800 W, Sine, 160 V, 280 V
Detailed product title
Detailed product title
APC SRVPM1KIL. UPS topology: Double conversion (online), Output capacity: 1 kVA, Output power: 800 W. AC plug types: C13 coupler, Plug: C14 coupler, Number of AC outlets: 3 AC outlets. Battery technology: Sealed Lead Acid (VRLA), Battery charge time: 4 h. Form factor: Tower, Product color: Black, Display type: LCD. Width: 145 mm, Depth: 288 mm, Height: 223 mm
