- SYA12K16RMI, 12 kVA, 8400 W, 7,5 min, 20,2 min, SYBT5, 0 - 40 °C
1 Images
Product description
Industry’s most space-optimized modular UPS solutions
Engineered to deliver the highest level of business continuity possible, the Symmetra LX uses a modular, redundant architecture that can scale power and run-time as demand increases or when higher levels of availability are required. Advancements in this next generation design greatly decrease foot print or U-space needed in an equipment rack, increase speed and ease of deployment and reduce repair time. With built-in network manageability and a comprehensive portfolio available from 4-16 kVA N+1, the on-line Symmetra LX is the choice to protect high-performance IT and telecom equipment in computer rooms and small data centers.
Engineered to deliver the highest level of business continuity possible, the Symmetra LX uses a modular, redundant architecture that can scale power and run-time as demand increases or when higher levels of availability are required. Advancements in this next generation design greatly decrease foot print or U-space needed in an equipment rack, increase speed and ease of deployment and reduce repair time. With built-in network manageability and a comprehensive portfolio available from 4-16 kVA N+1, the on-line Symmetra LX is the choice to protect high-performance IT and telecom equipment in computer rooms and small data centers.
Technical specifications
Merkmale
| Audible alarm(s) | Y |
| Emergency Power Off (EPO) | Y |
| Output power capacity | 12 kVA |
Batterie
| Replacement battery cartridge | SYBT5 |
| Typical backup time at half load | 20.2 min |
| Typical backup time at full load | 7.5 min |
Technische Details
| Output connections | (1) Hard Wire 3-wire (H N+ G) (8) IEC 320 C13 ( |
Verpackungsdaten
| Package weight | 290,000 g |
Leistung
| Battery type | Lead-Acid |
Betriebsbedingungen
| Operating relative humidity (H-H) | 0 - 95 |
| Storage temperature (T-T) | -15 - 45 |
| Operating temperature (T-T) | 0 - 40 |
| Operating altitude | 0 - 3000 |
| Storage relative humidity (H-H) | 0 - 95 |
Sonstige Funktionen
| Interface | DB-9 RS-232,Smart-Slot |
| I/O ports | (1) Hard Wire 3-wire (H N+ G) (8) IEC 320 C13 ( |
| Dimensions (WxDxH) | 472 x 688 x 838 |
| Package dimensions (WxDxH) | 599 x 997 x 1054 |
| Output power | 8,400 W |
| Nominal input voltage | 230-400 |
| Nominal output voltage | 230 |
| Output voltage note | 220: 230, 240 |
| Input connection type | Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH |
Gewicht und Abmessungen
| Weight | 242,740 g |
Logistische Daten
| Products per pallet | 1 ST |
ID: 100761
APC ID: SYA12K16RMI
SYA12K16RMI, 12 kVA, 8400 W, 7,5 min, 20,2 min, SYBT5, 0 - 40 °C
Detailed product title
Detailed product title
APC SYA12K16RMI. Ausgangskapazität: 12 kVA, Ausgangsleistung: 8400 W. Typische Backup-Zeit bei voller Belastung: 7,5 min, Typische B ackup-Zeit bei halber Belastung: 20,2 min, Batteriepatrone Wechsel: SYBT5. Gewicht: 242,7 kg, Paketgewicht: 290 kg. Produkte pro Pa ette: 1,00 Stück(e). Akku-/Batterietyp: Lead-Acid, Schnittstelle: DB-9 RS-232,Smart-Slot, Ausgang Anschlüsse: (1) Hard Wire 3-wire H N + G) (8) IEC 320 C13 (10) IEC 320 C19
