ID: 550343
HP Enterprise ID: P57686-B21
DL320 GEN11 3408U 1P 16G -STOCK
Detailed product title
Detailed product title
HPE ProLiant DL320 Gen11 3408U 1.8GHz 8-core 1P 16GB-R 8SFF 500W PS Server. Processor family: Intel Xeon Bronze, Processor frequency: 1.8 GHz, Processor model: 3408U. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory layout (slots x size): 1 x 16 GB. Total storage capacity: 0 GB, HDD interface: SATA. Ethernet LAN. Power supply: 500 W, Redundant power supply (RPS) support. Chassis type: Rack (1U)
4 Images
Internal memory 16 GB
Processor family Intel Xeon Bronze
Chassis type Rack (1U)
Gross:
incl.
taxes.
please ask for availability
Added to cart
Gross:
incl.
taxes.
please ask for availability
Product description
Are you looking to run edge AI workloads like Computer Vision that need GPU accelerators or distributed data solutions that require expandable storage? The HPE ProLiant DL320 Gen11 is a 1U 1P server with a unique compact design and workload-driven modular design that is purpose-built for edge computing delivering exceptional performance at 1P economics and an excellent choice for both virtualized and containerized workloads. Powered by 4th and 5th Gen Intel Xeon Scalable Processors with up to 60 cores, 270W, increased memory capability (up to 2 TB 5600 MT/s), and high-speed PCIe Gen5 supporting up to four single-wide GPUs (or two double-wide), the HPE ProLiant DL320 Gen11 server is a perfect low-cost, 1U 1P, performance solution. The HPE ProLiant Gen11 servers are engineered to optimize IT at the edge with a cloud operating experience, built-in security, and optimized performance for workloads to drive your business forward.
What is new supporting point:
Support for up to four single-wide or two double-wide GPUs in the front cage with the GPU CTO server.
Supports hot-pluggable or internal, high-availability RAID1 NVMe M.2 boot options.
Powered by the 4th and 5th Gen Intel Xeon Scalable Processors with next-generation 5nm technology that supports up to 60 cores at 270W and 16 DIMMs of DDR5 memory up to 5600 MT/s.
16 DIMMs per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x16 PCIe Gen5 and 1 OCP 3.0 slots.
Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
What is new supporting point:
Support for up to four single-wide or two double-wide GPUs in the front cage with the GPU CTO server.
Supports hot-pluggable or internal, high-availability RAID1 NVMe M.2 boot options.
Powered by the 4th and 5th Gen Intel Xeon Scalable Processors with next-generation 5nm technology that supports up to 60 cores at 270W and 16 DIMMs of DDR5 memory up to 5600 MT/s.
16 DIMMs per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x16 PCIe Gen5 and 1 OCP 3.0 slots.
Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
Technical specifications
Other features
| Internal memory type | DDR5-SDRAM |
Other features
| Security features | UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits. |
| Storage drive type | None ship standard, 8 SFF supported |
| Number of processors supported | 1 |
| Standard fans | 5x Standard Fans |
| Weight (imperial) | 56.879 lb |
| Dimensions (W x D x H) (imperial) | 23.62 x 36.06 x 9.49 |
Technical details
| Sustainability certificates | ENERGY STAR |
Other features
| Compatible operating systems | Microsoft Windows Server VMware ESXi Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Canonical Ubuntu Oracle Linux and Oracle VM Citrix Community Enterprise Linux (CentOS, Alma Linux, Rocky Linux) |
| Weight | 25,800 g |
| Height | 241 mm |
| Width | 600 mm |
| Depth | 916 mm |
Network
| Ethernet LAN | Yes |
Operational conditions
| Operating relative humidity (H-H) | 8 - 90 |
| Storage temperature (T-T) | -30 - 60 |
| Operating temperature (T-T) | 10 - 35 |
| Storage relative humidity (H-H) | 5 - 95 |
Power
| Number of main power supplies | 1 |
| Number of redundant power supplies supported | 2 |
| Number of redundant power supplies installed | 1 |
| Redundant power supply (RPS) support | Yes |
Power
| Power supply type | 1x HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit |
Performance
| Management platform | Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). Optional - HPE iLO Advanced, and HPE OneView Advanced. |
| Remote administration | iLO 6 ASIC |
Design
| Rack mounting | Yes |
Ports & interfaces
| VGA (D-Sub) ports quantity | 1 |
Operational conditions
| Operating altitude | 0 - 3050 |
| Non-operating altitude | 0 - 9144 |
Computer system
| Processor manufacturer | Intel |
| Processor family | Intel Xeon Bronze |
| Processor cores | 8 |
| Operating system installed | No |
| Internal memory | 16 GB |
Ports & interfaces
| Expansion slots | One PCIe Gen5 & One OCP 3.0 PCIe Gen5 |
Security
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
Network
| Ethernet interface type | Gigabit Ethernet |
Design
| Chassis type | Rack (1U) |
Power
| Power supply | 500 W |
Graphics
| Maximum graphics card memory | 16 MB |
Network
| LAN controller | Broadcom BCM5719 |
Storage
| HDD interface | SATA |
| RAID support | Yes |
| RAID levels | 0,1,5,10 |
| Number of HDDs supported | 8 |
| Supported RAID controllers | Intel VROC SATA for HPE ProLiant Gen11 |
| Supported SSD sizes | 2.5" |
| Number of SSDs supported | 8 |
| Hot-Plug support | Yes |
| Maximum storage capacity | 20 TB |
| Supported HDD sizes | 2.5 |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
Processor
| Maximum number of SMP processors | 2 |
Performance
| Motherboard chipset | Intel C741 |
Processor
| Number of processors installed | 1 |
Processor
| Processor cache type | L3 |
Graphics
| On-board graphics card | Yes |
Storage
| Optical drive type | No |
| SSD interface | PCI Express 4.0 |
| Total storage capacity | 0 GB |
Memory
| Memory slots | 16x DIMM |
| ECC | Yes |
| Maximum internal memory | 2,048 GB |
| Memory clock speed | 4,800 MHz |
| Memory layout (slots x size) | 1 x 16 |
Processor
| Processor model | 3408U |
| Processor cache | 22.5 MB |
| Processor boost frequency | 1.9 GHz |
| Processor frequency | 1.8 GHz |
