Product description
Are you looking for a scalable and cost optimized server solution for your virtualized and software-defined compute workloads?
The HPE ProLiant DL320 Gen11 server is a 1U 1P solution that delivers exceptional compute performance, upgraded high-speed data transfer rates, and increased maximum memory capacity and bandwidth, at 1P economics. Powered by 4th Gen Intel® Xeon® Scalable Processors with up to 32 cores, 270W, increased memory capability (up to 2 TB 4800 MT/s), and high-speed PCIe Gen5, the HPE ProLiant DL320 Gen11 server is a perfect low-cost, 1U 1P, performance solution.
The silicon root of trust anchors the server firmware, creating a fingerprint for the Intel Secure Processor that must be matched exactly, before the server will boot.
The HPE ProLiant DL320 Gen11 server is an excellent choice for virtualized workloads such as software-defined compute, CDN, VDI and VDI, and secure edge apps that require balancing processor, memory, and network
Features
Intuitive Cloud Operating Experience: Simple, Self-service, and Automated
- HPE ProLiant DL320 Gen11 servers are engineered for your hybrid world. The HPE ProLiant DL320 Gen11 servers simplify the way you control your business’s compute—from edge to cloud—with a cloud operating experience.
- Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a self-service console.
- Automate tasks for efficiency in deployment, instant scalability, and seamless, simplified support and lifecycle management reducing tasks and shortening maintenance windows.
- These experiences are engineered and built into all HPE ProLiant Gen11 servers, whether purchased as physical servers or consume as-a-service using HPE GreenLake as your compute and storage demands grow.
- Simplify and secure server management from edge to cloud with HPE GreenLake for Compute Ops Management. HPE GreenLake for Compute Ops Management is an as-a-service compute management experience that delivers greater simplicity, agility, and speed across your entire compute landscape, globally.
Trusted Security by Design: Uncompromising, Fundamental, and Protected
- The HPE ProLiant DL320 Gen11 server is tied into the silicon root of trust and the 4th Gen Intel® Xeon® Scalable Processor, a dedicated security processor embedded in the Intel Xeon system on a chip (SoC), to manage secure boot, memory encryption, and secure virtualization.
- HPE ProLiant Gen11 servers use the silicon root of trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the Intel® Xeon® Processor that must be matched exactly before the server will boot. This ensures malicious code is contained and healthy servers are protected.
- HPE ProLiant Gen11 servers continuously protect healthy servers by providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies and contains malicious code, and secure servers at the edge with IDevID certificates installed by default.
- HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of the operating system, application, and data connections, providing the fastest path to bring a server back online and into normal operations.
- From silicon to software, from factory to cloud, and from generation to generation, HPE ProLiant Gen11 is engineered with a fundamental security approach to defend against increasingly complex threats through an uncompromising commitment to constant security advancements that are built into our DNA.
Optimized Performance for your Workloads: Accelerated, Open, and Efficient
- The HPE ProLiant DL320 Gen11 server is an excellent choice for virtualized workloads such as software-defined compute, CDN, and VDI, and secure edge apps that require balancing processor, memory, and network bandwidth.
- Harness major computer performance. The HPE ProLiant DL320 Gen11 server is powered by 4th Gen Intel® Xeon® Scalable Processors with modern 5nm technology that support up to 32 cores and 270W TDP.
- Enjoy advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x16 PCIe Gen5 and 1 OCP slots to improve I/O throughput and reduce latency.
- Utilize 16 DIMM channels per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
- Benefit from real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.
Delivered As-a-Service
- The HPE ProLiant DL320 Gen11 server is supported by HPE GreenLake to simplify IT. With 24x7 monitoring and management, our experts do the heavy lifting to manage your environment with services built into consumption-based solutions.
- Hewlett Packard Enterprise provides customers choice in how they acquire and consume IT. Beyond traditional financing and leasing, HPE offers options that free trapped capital, accelerate infrastructure updates and provide for on-premises pay-per-use consumption with HPE GreenLake.
- Rapidly deploy a broad portfolio of cloud services such as, containers, compute, virtual machines (VMs), accelerated storage, data protection, and more. Workload-optimized, preconfigured solutions can be quickly on-boarded, accelerating your agility
The HPE ProLiant DL320 Gen11 server is a 1U 1P solution that delivers exceptional compute performance, upgraded high-speed data transfer rates, and increased maximum memory capacity and bandwidth, at 1P economics. Powered by 4th Gen Intel® Xeon® Scalable Processors with up to 32 cores, 270W, increased memory capability (up to 2 TB 4800 MT/s), and high-speed PCIe Gen5, the HPE ProLiant DL320 Gen11 server is a perfect low-cost, 1U 1P, performance solution.
The silicon root of trust anchors the server firmware, creating a fingerprint for the Intel Secure Processor that must be matched exactly, before the server will boot.
The HPE ProLiant DL320 Gen11 server is an excellent choice for virtualized workloads such as software-defined compute, CDN, VDI and VDI, and secure edge apps that require balancing processor, memory, and network
Features
Intuitive Cloud Operating Experience: Simple, Self-service, and Automated
- HPE ProLiant DL320 Gen11 servers are engineered for your hybrid world. The HPE ProLiant DL320 Gen11 servers simplify the way you control your business’s compute—from edge to cloud—with a cloud operating experience.
- Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a self-service console.
- Automate tasks for efficiency in deployment, instant scalability, and seamless, simplified support and lifecycle management reducing tasks and shortening maintenance windows.
- These experiences are engineered and built into all HPE ProLiant Gen11 servers, whether purchased as physical servers or consume as-a-service using HPE GreenLake as your compute and storage demands grow.
- Simplify and secure server management from edge to cloud with HPE GreenLake for Compute Ops Management. HPE GreenLake for Compute Ops Management is an as-a-service compute management experience that delivers greater simplicity, agility, and speed across your entire compute landscape, globally.
Trusted Security by Design: Uncompromising, Fundamental, and Protected
- The HPE ProLiant DL320 Gen11 server is tied into the silicon root of trust and the 4th Gen Intel® Xeon® Scalable Processor, a dedicated security processor embedded in the Intel Xeon system on a chip (SoC), to manage secure boot, memory encryption, and secure virtualization.
- HPE ProLiant Gen11 servers use the silicon root of trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the Intel® Xeon® Processor that must be matched exactly before the server will boot. This ensures malicious code is contained and healthy servers are protected.
- HPE ProLiant Gen11 servers continuously protect healthy servers by providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies and contains malicious code, and secure servers at the edge with IDevID certificates installed by default.
- HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of the operating system, application, and data connections, providing the fastest path to bring a server back online and into normal operations.
- From silicon to software, from factory to cloud, and from generation to generation, HPE ProLiant Gen11 is engineered with a fundamental security approach to defend against increasingly complex threats through an uncompromising commitment to constant security advancements that are built into our DNA.
Optimized Performance for your Workloads: Accelerated, Open, and Efficient
- The HPE ProLiant DL320 Gen11 server is an excellent choice for virtualized workloads such as software-defined compute, CDN, and VDI, and secure edge apps that require balancing processor, memory, and network bandwidth.
- Harness major computer performance. The HPE ProLiant DL320 Gen11 server is powered by 4th Gen Intel® Xeon® Scalable Processors with modern 5nm technology that support up to 32 cores and 270W TDP.
- Enjoy advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x16 PCIe Gen5 and 1 OCP slots to improve I/O throughput and reduce latency.
- Utilize 16 DIMM channels per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
- Benefit from real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.
Delivered As-a-Service
- The HPE ProLiant DL320 Gen11 server is supported by HPE GreenLake to simplify IT. With 24x7 monitoring and management, our experts do the heavy lifting to manage your environment with services built into consumption-based solutions.
- Hewlett Packard Enterprise provides customers choice in how they acquire and consume IT. Beyond traditional financing and leasing, HPE offers options that free trapped capital, accelerate infrastructure updates and provide for on-premises pay-per-use consumption with HPE GreenLake.
- Rapidly deploy a broad portfolio of cloud services such as, containers, compute, virtual machines (VMs), accelerated storage, data protection, and more. Workload-optimized, preconfigured solutions can be quickly on-boarded, accelerating your agility
Technical specifications
Design
Chassis type | Rack (1U) |
Anschlüsse und Schnittstellen
Ethernet LAN ports | 2 |
VGA (D-Sub) ports | 1 |
USB 3.2 Gen 1 Typ A ports | 3 |
Ethernet LAN | Y |
Prozessor
Processor | 3408U |
Processor cores | 16 |
Maximum number of SMP processors | 2 |
Number of processors installed | 1 |
Processor cache | 22.5 MB |
Processor boost frequency | 1.9 GHz |
Processor frequency | 1.8 GHz |
Speicher
Internal memory type | DDR5-SDRAM |
Memory slots | 16x DIMM |
ECC | Y |
Max. RAM memory | 2,048 GB |
Memory clock speed | 4,800 MHz |
RAM memory | 16 GB |
Memory layout (slots x size) | 1 x 16 |
Netzwerk
LAN controller | Broadcom BCM5719 |
Ethernet interface type | Gigabit Ethernet |
Speichermedium
Optical drive | N |
HDD interface | SATA |
RAID support | Y |
Number of HDDs supported | 4 |
Supported SSD sizes | 3.5" |
Number of SSDs supported | 4 |
Supported HDD sizes | 3.5 |
Software
Operating system | N |
Leistungen
Trusted Platform Module (TPM) version | 2.0 |
Trusted Platform Module (TPM) | Y |
Hot-Plug support | Y |
Computersystem
Processor manufacturer | Intel |
Processor family | Intel Xeon Bronze |
Grafik
On-board graphics card | Y |
Thin Client
Motherboard chipset | Intel C741 |
Management-Funktionen
Remote administration | iLO 6 ASIC |
Nachhaltigkeit
Sustainability certificates | ENERGY STAR |
Festplatte
RAID levels | 0,1,5,10 |
Leistung
Number of redundant power supplies supported | 2 |
Number of redundant power supplies installed | 1 |
Redundant power supply (RPS) support | Y |
Betriebsbedingungen
Operating relative humidity (H-H) | 8 - 90 |
Storage temperature (T-T) | -30 - 60 |
Operating temperature (T-T) | 10 - 35 |
Operating altitude | 0 - 3050 |
Storage relative humidity (H-H) | 5 - 95 |
Non-operating altitude | 0 - 9144 |
Sonstige Funktionen
Compatible operating systems | Microsoft WindowsServer VMware ESXi RedHat Enter |
Rack mounting | Y |
Power supply | 500 W |
Maximum storage capacity | 24 TB |
Maximum graphics adapter memory | 16 MB |
Gewicht und Abmessungen
Height | 42.8 mm |
Width | 434.6 mm |
Depth | 664.7 mm |
Downloads
550344_document_EN_001
PDF Download
ID: 550344
HP Enterprise ID: P57685-B21
DL320 GEN11 3408U 1P 16G -STOCK
Detailed product title
Detailed product title
DL320 GEN11 3408U 1P 16G -STOCK .
2 Images
RAM memory 16 GB
Processor family Intel Xeon Bronze
Chassis type Rack (1U)
Gross:
incl.
vat.
will be ordered especially for you
Added to cart
Gross:
incl.
vat.
will be ordered especially for you
Product description
Are you looking for a scalable and cost optimized server solution for your virtualized and software-defined compute workloads?
The HPE ProLiant DL320 Gen11 server is a 1U 1P solution that delivers exceptional compute performance, upgraded high-speed data transfer rates, and increased maximum memory capacity and bandwidth, at 1P economics. Powered by 4th Gen Intel® Xeon® Scalable Processors with up to 32 cores, 270W, increased memory capability (up to 2 TB 4800 MT/s), and high-speed PCIe Gen5, the HPE ProLiant DL320 Gen11 server is a perfect low-cost, 1U 1P, performance solution.
The silicon root of trust anchors the server firmware, creating a fingerprint for the Intel Secure Processor that must be matched exactly, before the server will boot.
The HPE ProLiant DL320 Gen11 server is an excellent choice for virtualized workloads such as software-defined compute, CDN, VDI and VDI, and secure edge apps that require balancing processor, memory, and network
Features
Intuitive Cloud Operating Experience: Simple, Self-service, and Automated
- HPE ProLiant DL320 Gen11 servers are engineered for your hybrid world. The HPE ProLiant DL320 Gen11 servers simplify the way you control your business’s compute—from edge to cloud—with a cloud operating experience.
- Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a self-service console.
- Automate tasks for efficiency in deployment, instant scalability, and seamless, simplified support and lifecycle management reducing tasks and shortening maintenance windows.
- These experiences are engineered and built into all HPE ProLiant Gen11 servers, whether purchased as physical servers or consume as-a-service using HPE GreenLake as your compute and storage demands grow.
- Simplify and secure server management from edge to cloud with HPE GreenLake for Compute Ops Management. HPE GreenLake for Compute Ops Management is an as-a-service compute management experience that delivers greater simplicity, agility, and speed across your entire compute landscape, globally.
Trusted Security by Design: Uncompromising, Fundamental, and Protected
- The HPE ProLiant DL320 Gen11 server is tied into the silicon root of trust and the 4th Gen Intel® Xeon® Scalable Processor, a dedicated security processor embedded in the Intel Xeon system on a chip (SoC), to manage secure boot, memory encryption, and secure virtualization.
- HPE ProLiant Gen11 servers use the silicon root of trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the Intel® Xeon® Processor that must be matched exactly before the server will boot. This ensures malicious code is contained and healthy servers are protected.
- HPE ProLiant Gen11 servers continuously protect healthy servers by providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies and contains malicious code, and secure servers at the edge with IDevID certificates installed by default.
- HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of the operating system, application, and data connections, providing the fastest path to bring a server back online and into normal operations.
- From silicon to software, from factory to cloud, and from generation to generation, HPE ProLiant Gen11 is engineered with a fundamental security approach to defend against increasingly complex threats through an uncompromising commitment to constant security advancements that are built into our DNA.
Optimized Performance for your Workloads: Accelerated, Open, and Efficient
- The HPE ProLiant DL320 Gen11 server is an excellent choice for virtualized workloads such as software-defined compute, CDN, and VDI, and secure edge apps that require balancing processor, memory, and network bandwidth.
- Harness major computer performance. The HPE ProLiant DL320 Gen11 server is powered by 4th Gen Intel® Xeon® Scalable Processors with modern 5nm technology that support up to 32 cores and 270W TDP.
- Enjoy advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x16 PCIe Gen5 and 1 OCP slots to improve I/O throughput and reduce latency.
- Utilize 16 DIMM channels per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
- Benefit from real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.
Delivered As-a-Service
- The HPE ProLiant DL320 Gen11 server is supported by HPE GreenLake to simplify IT. With 24x7 monitoring and management, our experts do the heavy lifting to manage your environment with services built into consumption-based solutions.
- Hewlett Packard Enterprise provides customers choice in how they acquire and consume IT. Beyond traditional financing and leasing, HPE offers options that free trapped capital, accelerate infrastructure updates and provide for on-premises pay-per-use consumption with HPE GreenLake.
- Rapidly deploy a broad portfolio of cloud services such as, containers, compute, virtual machines (VMs), accelerated storage, data protection, and more. Workload-optimized, preconfigured solutions can be quickly on-boarded, accelerating your agility
The HPE ProLiant DL320 Gen11 server is a 1U 1P solution that delivers exceptional compute performance, upgraded high-speed data transfer rates, and increased maximum memory capacity and bandwidth, at 1P economics. Powered by 4th Gen Intel® Xeon® Scalable Processors with up to 32 cores, 270W, increased memory capability (up to 2 TB 4800 MT/s), and high-speed PCIe Gen5, the HPE ProLiant DL320 Gen11 server is a perfect low-cost, 1U 1P, performance solution.
The silicon root of trust anchors the server firmware, creating a fingerprint for the Intel Secure Processor that must be matched exactly, before the server will boot.
The HPE ProLiant DL320 Gen11 server is an excellent choice for virtualized workloads such as software-defined compute, CDN, VDI and VDI, and secure edge apps that require balancing processor, memory, and network
Features
Intuitive Cloud Operating Experience: Simple, Self-service, and Automated
- HPE ProLiant DL320 Gen11 servers are engineered for your hybrid world. The HPE ProLiant DL320 Gen11 servers simplify the way you control your business’s compute—from edge to cloud—with a cloud operating experience.
- Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a self-service console.
- Automate tasks for efficiency in deployment, instant scalability, and seamless, simplified support and lifecycle management reducing tasks and shortening maintenance windows.
- These experiences are engineered and built into all HPE ProLiant Gen11 servers, whether purchased as physical servers or consume as-a-service using HPE GreenLake as your compute and storage demands grow.
- Simplify and secure server management from edge to cloud with HPE GreenLake for Compute Ops Management. HPE GreenLake for Compute Ops Management is an as-a-service compute management experience that delivers greater simplicity, agility, and speed across your entire compute landscape, globally.
Trusted Security by Design: Uncompromising, Fundamental, and Protected
- The HPE ProLiant DL320 Gen11 server is tied into the silicon root of trust and the 4th Gen Intel® Xeon® Scalable Processor, a dedicated security processor embedded in the Intel Xeon system on a chip (SoC), to manage secure boot, memory encryption, and secure virtualization.
- HPE ProLiant Gen11 servers use the silicon root of trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the Intel® Xeon® Processor that must be matched exactly before the server will boot. This ensures malicious code is contained and healthy servers are protected.
- HPE ProLiant Gen11 servers continuously protect healthy servers by providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies and contains malicious code, and secure servers at the edge with IDevID certificates installed by default.
- HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of the operating system, application, and data connections, providing the fastest path to bring a server back online and into normal operations.
- From silicon to software, from factory to cloud, and from generation to generation, HPE ProLiant Gen11 is engineered with a fundamental security approach to defend against increasingly complex threats through an uncompromising commitment to constant security advancements that are built into our DNA.
Optimized Performance for your Workloads: Accelerated, Open, and Efficient
- The HPE ProLiant DL320 Gen11 server is an excellent choice for virtualized workloads such as software-defined compute, CDN, and VDI, and secure edge apps that require balancing processor, memory, and network bandwidth.
- Harness major computer performance. The HPE ProLiant DL320 Gen11 server is powered by 4th Gen Intel® Xeon® Scalable Processors with modern 5nm technology that support up to 32 cores and 270W TDP.
- Enjoy advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x16 PCIe Gen5 and 1 OCP slots to improve I/O throughput and reduce latency.
- Utilize 16 DIMM channels per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
- Benefit from real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.
Delivered As-a-Service
- The HPE ProLiant DL320 Gen11 server is supported by HPE GreenLake to simplify IT. With 24x7 monitoring and management, our experts do the heavy lifting to manage your environment with services built into consumption-based solutions.
- Hewlett Packard Enterprise provides customers choice in how they acquire and consume IT. Beyond traditional financing and leasing, HPE offers options that free trapped capital, accelerate infrastructure updates and provide for on-premises pay-per-use consumption with HPE GreenLake.
- Rapidly deploy a broad portfolio of cloud services such as, containers, compute, virtual machines (VMs), accelerated storage, data protection, and more. Workload-optimized, preconfigured solutions can be quickly on-boarded, accelerating your agility
Technical specifications
Design
Chassis type | Rack (1U) |
Anschlüsse und Schnittstellen
Ethernet LAN ports | 2 |
VGA (D-Sub) ports | 1 |
USB 3.2 Gen 1 Typ A ports | 3 |
Ethernet LAN | Y |
Prozessor
Processor | 3408U |
Processor cores | 16 |
Maximum number of SMP processors | 2 |
Number of processors installed | 1 |
Processor cache | 22.5 MB |
Processor boost frequency | 1.9 GHz |
Processor frequency | 1.8 GHz |
Speicher
Internal memory type | DDR5-SDRAM |
Memory slots | 16x DIMM |
ECC | Y |
Max. RAM memory | 2,048 GB |
Memory clock speed | 4,800 MHz |
RAM memory | 16 GB |
Memory layout (slots x size) | 1 x 16 |
Netzwerk
LAN controller | Broadcom BCM5719 |
Ethernet interface type | Gigabit Ethernet |
Speichermedium
Optical drive | N |
HDD interface | SATA |
RAID support | Y |
Number of HDDs supported | 4 |
Supported SSD sizes | 3.5" |
Number of SSDs supported | 4 |
Supported HDD sizes | 3.5 |
Software
Operating system | N |
Leistungen
Trusted Platform Module (TPM) version | 2.0 |
Trusted Platform Module (TPM) | Y |
Hot-Plug support | Y |
Computersystem
Processor manufacturer | Intel |
Processor family | Intel Xeon Bronze |
Grafik
On-board graphics card | Y |
Thin Client
Motherboard chipset | Intel C741 |
Management-Funktionen
Remote administration | iLO 6 ASIC |
Nachhaltigkeit
Sustainability certificates | ENERGY STAR |
Festplatte
RAID levels | 0,1,5,10 |
Leistung
Number of redundant power supplies supported | 2 |
Number of redundant power supplies installed | 1 |
Redundant power supply (RPS) support | Y |
Betriebsbedingungen
Operating relative humidity (H-H) | 8 - 90 |
Storage temperature (T-T) | -30 - 60 |
Operating temperature (T-T) | 10 - 35 |
Operating altitude | 0 - 3050 |
Storage relative humidity (H-H) | 5 - 95 |
Non-operating altitude | 0 - 9144 |
Sonstige Funktionen
Compatible operating systems | Microsoft WindowsServer VMware ESXi RedHat Enter |
Rack mounting | Y |
Power supply | 500 W |
Maximum storage capacity | 24 TB |
Maximum graphics adapter memory | 16 MB |
Gewicht und Abmessungen
Height | 42.8 mm |
Width | 434.6 mm |
Depth | 664.7 mm |
Downloads
550344_document_EN_001
PDF Download
