ID: 550321
HP Enterprise ID: P70542-421
HPE ProLiant DL360 Gen11 4514Y 2.0GHz 8-core 1P 32GB-R MR408i-o NC 8SFF 1000W PS Server
Detailed product title
Detailed product title
HPE ProLiant DL360 Gen11 4514Y 2.0GHz 8-core 1P 32GB-R MR408i-o NC 8SFF 1000W PS Server HPE ProLiant DL360 Gen11 4514Y 2.0GHz 8-core 1P 32GB-R MR408i-o NC 8SFF 1000W PS Server
2 Images
Internal memory 32
Processor family Intel Xeon Silver
Chassis type Rack (1U)
Gross:
incl.
taxes.
please ask for availability
Added to cart
Gross:
incl.
taxes.
please ask for availability
Product description
Are you looking for a scalable, compute-dense solution for hybrid cloud or other data workloads in a virtualized and containerized environment? The HPE ProLiant DL360 Gen11 server is a rack-optimized, 1U 2P solution that delivers exceptional compute performance, upgraded high-speed data transfer rate, and memory depth at 2P compute capability. Powered by 4th and 5th Gen Intel Xeon Scalable Processors with up to 64 cores, 8 TB of memory, and 20 EDSFF drives as well as increased memory bandwidth and high-speed PCIe Gen5 I/O, the HPE ProLiant DL360 Gen11 server is a perfect solution for Electronic Design Automation (EDA), CAD, and VDI. The HPE ProLiant 360 Gen11 server is engineered to optimize IT with a cloud operating experience, built-in security, and optimized performance for workloads to drive your business forward.
What is new supporting point:
Powered by 5th Gen Intel Xeon Scalable Processors that supports up to 64 cores & 385W, and 16 DIMMs for up to 8 TB of high bandwidth DDR5 memory up to 5600 MHz.
16 DIMMs per processor for up to 8 TB total DDR5 memory per server with increased performance, High Bandwidth Memory (HBM) support, and lower power requirements.
Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2 x16 PCIe Gen5 and 2 OCP slots.
Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
Supports up to three single-wide (SW) GPUs[1] to accelerate graphic intense workloads.
Supports Liquid Cooling Modules for highest thermal design points (TDPs).
What is new supporting point:
Powered by 5th Gen Intel Xeon Scalable Processors that supports up to 64 cores & 385W, and 16 DIMMs for up to 8 TB of high bandwidth DDR5 memory up to 5600 MHz.
16 DIMMs per processor for up to 8 TB total DDR5 memory per server with increased performance, High Bandwidth Memory (HBM) support, and lower power requirements.
Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2 x16 PCIe Gen5 and 2 OCP slots.
Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
Supports up to three single-wide (SW) GPUs[1] to accelerate graphic intense workloads.
Supports Liquid Cooling Modules for highest thermal design points (TDPs).
Technical specifications
Other features
| Security features | UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs. |
| Storage drive type | None ship standard, 8 SFF supported |
| Number of processors supported | 1 |
| Standard fans | 5x Standard Fans |
| Weight (imperial) | 71.275 |
| Dimensions (W x D x H) (imperial) | 9.49 x 23.62 x 38.98 |
Sustainability
| Sustainability certificates | ENERGY STAR |
Power
| Number of main power supplies | 1 |
| Number of redundant power supplies supported | 2 |
| Number of redundant power supplies installed | 1 |
| Redundant power supply (RPS) support | Yes |
Weight & dimensions
| Weight | 32,330 |
| Height | 990 |
| Width | 241 |
| Depth | 600 |
Software
| Compatible operating systems | 001:Windows Server |
Power
| Power supply type | 1x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit |
Performance
| Management platform | Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). |
| Remote administration | iLO 6 ASIC |
Operational conditions
| Operating relative humidity (H-H) | 8 - 90 |
| Storage temperature (T-T) | -30 - 60 |
| Operating temperature (T-T) | 10 - 35 |
| Operating altitude | 0 - 3050 |
| Storage relative humidity (H-H) | 5 - 95 |
| Non-operating altitude | 0 - 9144 |
Design
| Rack mounting | Yes |
Ports & interfaces
| Expansion slots | 2-slots (x16 FH, x16 HH) as standard. Upgradeable to 3rd slot in HH (or remove Slot 2 bracket to be FH at Slot 3) in a 2nd processor configuration. And maximum 2 OCP 3.0 PCIe5 slots. |
| VGA (D-Sub) ports quantity | 1 |
Network
| Ethernet interface type | 10 Gigabit Ethernet |
Design
| Chassis type | Rack (1U) |
Power
| Power supply | 1,000 |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
Graphics
| Maximum graphics card memory | 16 |
Network
| LAN controller | Broadcom BCM57416 |
| Ethernet LAN | Yes |
Storage
| HDD interface | SATA,Serial Attached SCSI (SAS) |
| RAID support | Yes |
| RAID levels | 0,1,5,6,10,50,60 |
| Number of HDDs supported | 8 |
| Supported RAID controllers | HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller |
| Supported SSD sizes | 2.5" |
| Number of SSDs supported | 8 |
| Hot-Plug support | Yes |
| Maximum storage capacity | 153.6 |
| Supported HDD sizes | 2.5 |
Performance
| Motherboard chipset | Intel C741 |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
Graphics
| On-board graphics card | Yes |
Storage
| Optical drive type | No |
| SSD interface | PCI Express 4.0 |
| Total storage capacity | 0 |
Memory
| Internal memory type | DDR5-SDRAM |
| Memory slots | 32x DIMM |
| ECC | Yes |
| Maximum internal memory | 8,192 |
| Internal memory | 32 |
| Memory layout (slots x size) | 1 x 32 |
Processor
| Maximum number of SMP processors | 2 |
Processor
| Processor manufacturer | Intel |
| Processor family | Intel Xeon Silver |
| Processor model | 4514Y |
| Processor cores | 16 |
| Processor cache type | L3 |
| Number of processors installed | 1 |
| Processor cache | 30 |
| Processor boost frequency | 3.4 |
Processor
| Processor frequency | 2 |
Memory
| Memory clock speed | 5,600 |
