- Smart-UPS SRT 5000VA RM 230V schwarz
+1 Images
6 Images
Product description
APC Smart UPS SRT
Die APC Smart UPS SRT ist ein optimales USV-System für die IT-Umgebung. Sie besitzt eine innovative D oppelwandler Technologie mit höchster Klassifizierung nach VFI-SS-111. Sie kann wahlweise als Stand-Alone Towergerät oder in ein 19 -Rack integriert werden. Der Platzbedarf im Rack beträgt in der RMXLI-Variante 3 HE. Durch das Hinzufügen von externen Batteriepac s ist die Autonomiezeit erweiterbar.
Technical specifications
Logistics data
| Products per pallet | 6 ST |
Weight & dimensions
| Weight | 54,430 g |
Power
| Battery recharge time | 1.5 std |
| Surge protection | Y |
Lieferumfang
| Rack mount kit | Y |
Verpackungsdaten
| Warranty card | Y |
| Quick installation guide | Y |
| Package weight | 66,860 g |
| Package depth | 960 mm |
| Package width | 610 mm |
| Package height | 330 mm |
Sonstige Funktionen
| USB port | Y |
| Input frequency | 40 - 70 |
| Output power | 4,500 W |
| Noise level | 55 dB |
Sustainability
| Sustainability certificates | ENERGY STAR |
| Compliance certificates | RoHS |
Operational conditions
| Operating relative humidity (H-H) | 0 - 95 |
| Storage temperature (T-T) | -15 - 45 |
| Operating temperature (T-T) | 0 - 40 |
| Operating altitude | 0 - 3000 |
| Storage relative humidity (H-H) | 0 - 95 |
| Non-operating altitude | 0 - 15000 |
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
| Hot-swap battery | Y |
| Waveform | Sine |
| Replacement battery cartridge | APCRBC140 |
| Cold start | Y |
| Automatic battery test | Y |
| Typical backup time at half load | 11.8 min |
| Battery capacity | 845 Vah |
| Typical backup time at full load | 4 min |
| Battery life (max) | 5 |
Features
| Height | 130 mm |
| Width | 432 mm |
| Depth | 719 mm |
| Audible alarm(s) | Y |
| Output frequency regulation | 50/60 |
| Crest factor | 3:1 |
| UPS topology | Double-conversion (Online) |
| Auto-restart | Y |
| Emergency Power Off (EPO) | Y |
| Efficiency | 94.1 % |
| Surge energy rating | 480 J |
| Output power capacity | 5 kVA |
| Output voltage Total Harmonic Distortion (THD) | 3 % |
| Input operation voltage (max) | 275 V |
| Input operation voltage (min) | 100 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
Mouse
| Form factor | Rackmount |
| Certification | REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE |
Ports & interfaces
| Serial interface type | RJ-45 |
| Power plug | Hardwire |
| AC outlet types | C13 coupler,C19 coupler |
| Number of output IEC jumpers | 2 |
| Serial interface | Y |
| SmartSlot | Y |
| AC outlets quantity | 10 AC out |
Design
| Product colour | Black |
| Temperature sensor | Y |
| Rack capacity | 3U |
Downloads
126047_document_DE_001
PDF Download
ID: 126047
APC ID: SRT5KRMXLI
Smart-UPS SRT 5000VA RM 230V schwarz
Detailed product title
Detailed product title
APC Smart-UPS SRT, 5000VA, RM 3HE, 230V, schwarz, Bleisäure, Wartungsfrei, versiegelt, auslaufsicher, USB, RJ-45, EPO, 2 Jahre Bring -In Herstellergarantie
