Name: HPE ProLiant ML110 Gen11 Intel Xeon Silver 4410Y 2.0GHz 12-core 1P 32GB-R VROC 8SFF 1000W RPS Server
Brand: 60000024
SKU: 550330

text.skipToContent text.skipToNavigation

HPE ProLiant ML110 Gen11 Intel Xeon Silver 4410Y 2.0GHz 12-core 1P 32GB-R VROC 8SFF 1000W RPS Server

ID: 550330 HP Enterprise ID: P55640-421

HPE ProLiant ML110 Gen11 Intel Xeon Silver 4410Y 2.0GHz 12-core 1P 32GB-R VROC 8SFF 1000W RPS Server

Detailed product title

HPE ProLiant ML110 Gen11 Intel Xeon Silver 4410Y 2.0GHz 12-core 1P 32GB-R VROC 8SFF 1000W RPS Server

Internal memory 32 GB

Processor family Intel Xeon Silver

Chassis type Tower (4.5U)

ship in 4-7 days

Added to cart

ship in 4-7 days

Product description

Are you looking for a tower server with enterprise-class reliability and performance at an exceptional price to meet the needs of your growing business? The HPE ProLiant ML110 Gen11 Server is an optimized tower server with a processor that offers performance, expandability and scalability at an affordable price. It also supports the 4th and 5th Generation Intel Xeon Scalable processor, HPE DDR5 SmartMemory with a maximum of 1536 GB, four x16 PCIe Gen5 slots, one x16 OCP3 slot and eight LFF or 16 SFF drives. With 5.5U rack capacity, it can be easily converted to a rack. The HPE ProLiant ML110 Gen11 Server also has an optional redundant fan and redundant power supply to meet the needs of automatic failover, making it the ideal server for small to medium-sized businesses and remote offices and branch offices.

Technical specifications

Other features

Power supply type

1x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit

Other features

Management platform

Included: HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional: HPE iLO Advanced, HPE OneView Advanced (require licenses) and HPE Compute Ops Management. Refer to the iLO 6 User Guide

Other features

Security features	UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Front bezel key-lock feature, Intrusion cable (Optional), Padlock slot and Kensington Lock slot support. For full security features refer to the QuickSpecs.
Storage drive type	None ship standard, 8 SFF supported
Standard fans	2x Standard Fans

Certificates

Sustainability certificates

ENERGY STAR

Power

Number of main power supplies	1
Redundant power supply (RPS) support	Yes

Performance

Remote administration

iLO 5 ASIC

Weight & dimensions

Height	462.5 mm
Width	174 mm
Depth	648 mm

Ports & interfaces

VGA (D-Sub) ports quantity

Ports & interfaces

Expansion slots	Default with 2 x16 PCIe 5.0 Slots and 1 x16 OCP3 slot.
Serial ports quantity	1

Security

Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes

Network

Ethernet interface type

Gigabit Ethernet

Power

Power supply

1,000 W

Processor special features

Intel Secure Key Technology version	1.00
Intel Smart Response Technology version	1.00
Intel TSX-NI version	0.00
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Intel Trusted Execution Technology	Yes
CPU configuration (max)	1
Intel VT-x with Extended Page Tables (EPT)	Yes
Embedded options available	No
Intel TSX-NI	Yes
Intel 64	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Stable Image Platform Program (SIPP) version	0
Intel Virtualization Technology (VT-x)	Yes

Graphics

Maximum graphics card memory

16 MB

Network

LAN controller

Intel 369i

Software

Compatible operating systems

001:Windows Server 2012

Storage

HDD interface	001:SATA,Serial Attached SCSI
RAID support	Yes
RAID levels	0,1,5,10
Number of HDDs supported	4
Supported RAID controllers	Embedded Intel VROC SATA/NVMe
Supported SSD sizes	3.5"
Number of SSDs supported	4
Hot-Plug support	Yes
Supported HDD sizes	3.5

Memory

Internal memory type	DDR5-SDRAM
Memory slots	24x DIMM
Maximum internal memory	1,536 GB
Internal memory	32 GB
Memory layout (slots x size)	1 x 32

Processor

Maximum number of SMP processors

Performance

Motherboard chipset

Intel C622

Processor

Number of processors supported	1
Configurable TDP-down	4.5 W

Ports & interfaces

DisplayPorts quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4

Network

Ethernet LAN

Graphics

On-board graphics card

Storage

Optical drive type	No
SSD interface	PCI Express 4.0

Memory

Memory clock speed

4,800 MHz

Processor

Processor manufacturer	Intel
Processor family	Intel Xeon Silver
Processor model	4410Y
Processor cores	12
Bus type	OPI
Processor cache type	L3
Number of processors installed	1
Processor cache	30 MB
Processor boost frequency	3.2 GHz
Processor frequency	2 GHz

Design

Chassis type

Tower (4.5U)
