HPE ProLiant ML110 Gen11 Server 4 TB Turm (4.5U) Intel Xeon Bronze 3508U 2,1 GHz 32 GB DDR5-SDRAM 2000 W

ID: 550345 HP Enterprise ID: P71647-425

HPE ProLiant ML110 Gen11 Server 4 TB Turm (4.5U) Intel Xeon Bronze 3508U 2,1 GHz 32 GB DDR5-SDRAM 2000 W

Detailed product title

HPE ProLiant ML110 Gen11 3508U 2.1GHz 8-core 1P 32GB-R VROC 4LFF 2x2TB HDD 2x1000W RPS EU Server. Processor family: Intel Xeon Bronze, Processor frequency: 2.1 GHz, Processor model: 3508U. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM, Memory layout (slots x size): 1 x 32 GB. Total storage capacity: 4 TB, HDD size: 3.5", HDD interface: SATA III. Ethernet LAN. Power supply: 1000 W, Redundant power supply (RPS) support. Chassis type: Tower (4.5U)

Internal memory 32 GB

Processor family Intel Xeon Bronze

Chassis type Tower (4.5U)

ship in 4-7 days

Added to cart

ship in 4-7 days

Product description

HPE ProLiant ML110 Gen11 servers are designed for your hybrid world. HPE ProLiant Gen11 servers simplify the way you control your company's computing - from edge to cloud - with a cloud operating experience. The HPE ProLiant ML110 Gen11 server uses the Silicon Root of Trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the Intel processor that must be precisely matched for the server to boot, ensuring malicious code is stopped and healthy servers are protected. The HPE ProLiant ML110 Gen11 server is an excellent choice for computing and storage workloads (IT infrastructure, data management, VDI, ERP/CRM) that require excellent performance and network and I/O bandwidth. The HPE ProLiant ML110 Gen11 server comes with a full range of HPE services to help customers deploy their systems with confidence, low risk, and ensure agility and stability.

Technical specifications

Other features

Management platform

Included: HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional: HPE iLO Advanced, HPE OneView Advanced (require licenses) and HPE Compute Ops Management. Refer to the iLO 6 User Guide

Other features

Security features	UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Front bezel key-lock feature, Intrusion cable (Included), Padlock slot and Kensington Lock slot support.
Storage drive type	2x HPE 2TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD
Standard fans	2x Standard Fans

Operational conditions

Operating relative humidity (H-H)	8 - 90
Storage temperature (T-T)	-30 - 60
Operating temperature (T-T)	10 - 35
Operating altitude	0 - 3050

Certificates

Sustainability certificates

ENERGY STAR

Power

Number of main power supplies	2
Number of redundant power supplies installed	1
Redundant power supply (RPS) support	Yes

Power

Power supply type

2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit

Performance

Remote administration

iLO 5 ASIC

Operational conditions

Non-operating altitude

0 - 9144

Weight & dimensions

Weight	20,400 g
Height	462 mm
Width	195 mm
Depth	587 mm

Ports & interfaces

VGA (D-Sub) ports quantity

Operational conditions

Storage relative humidity (H-H)

5 - 95

Design

Product colour

Black

Ports & interfaces

Expansion slots	Default with 2 x16 PCIe 5.0 Slots and 1 x16 OCP3 slot.
Serial ports quantity	1

Security

Trusted Platform Module (TPM) version

2.0

Network

Ethernet interface type

Gigabit Ethernet

Power

Power supply

1,000 W

Processor special features

Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Embedded options available	No
Intel TSX-NI	Yes
Intel 64	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Virtualization Technology (VT-x)	Yes

Expansion slots

PCI Express x16 slots

Graphics

Maximum graphics card memory

16 MB

Network

LAN controller

Broadcom BCM5720

Software

Compatible operating systems

001:Windows Server 2012

Storage

HDD interface	SATA III
Number of HDDs installed	2
RAID support	Yes
RAID levels	0,1,5,10
Number of HDDs supported	4
Supported RAID controllers	Embedded Intel VROC SATA/NVMe
Supported SSD sizes	3.5"
Number of SSDs supported	4
Hot-Plug support	Yes
HDD capacity	2,000 GB
Maximum storage capacity	192 TB
HDD size	3.5
Supported HDD sizes	3.5

Performance

BIOS type	UEFI
Motherboard chipset	Intel C741
Trusted Platform Module (TPM)	Yes

Storage

Optical drive type	No
SSD interface	SATA III
Total storage capacity	4,000 GB

Memory

Internal memory type	DDR5-SDRAM
Memory slots	16x DIMM
ECC	Yes
Maximum internal memory	1,500 GB
Memory clock speed	5,600 MHz
Internal memory	32 GB
Memory layout (slots x size)	1 x 32

Processor

Maximum number of SMP processors

Processor

Processor cache type	L3
Number of processors supported	1
Processor cache	22.5 MB

Processor

Processor boost frequency

2.2 GHz

Ports & interfaces

Ethernet LAN (RJ-45) ports	2
DisplayPorts quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3

Network

Ethernet LAN

Graphics

On-board graphics card

Processor

Processor manufacturer	Intel
Processor family	Intel Xeon Bronze
Processor model	3508U
Processor cores	8
Number of processors installed	1
Processor frequency	2.1 GHz

Design

Chassis type

Tower (4.5U)
